Project Description

  • SXJ005N Prime series Balanced XLR female to 6.35 mm stereo JACK Microphone link Cable

SXJ005N Prime Series Balanced Microphone Link Cable with Yongsheng XLR Female to 1/4″ TRS JACK

The Prime series balanced XLR microphone cable featuring high quality Neutrik AG NC3FXX and NC3MXX connectors and the ultra flexible microphone cableThe SXJ005N Prime series balanced 3-pin XLR female to 1/4″ stereo JACK microphone cable featuring high quality Yongsheng YS136Nand YS228 connectors and the ultra flexible microphone cable. It comes in different lengths from 0.5 meters to 30 meters, providing solutions for all applications.

  • Oxygen free copper (OFC)
  • 24 AWG thin and dense stranded conductors
  • 2C*20/0.12mm + 96/0.12mm (braided shield)
  • Ultra-high density braided shielding
  • Ultra flexible PVC jacket
  • 6.8 mm (Ø) outer diameter, black
  • Yongsheng JACK connector, Nickel
  • 60 mm black shrink sleeve for protect your cable
  • 60 mm transparent shrink sleeve for tag your cables easily

6.35 mm TRS JACK to 3-pin XLR female microphone cable Wiring diagram

Specifications

  • Connector 1 : 3-pin XLR female connector, nickel, YS136N / Yongsheng
  • Connector 2 : 1/4″ stereo JACK plug, nickel, YS228 / Yongsheng
  • Cable Type:  24 AWG Balanced microphone cable, braided shielding, SMC211

Packaging

  • Sleeve, plastic bag, paper box and blister packing are available;
  • Special packaging on request.
Quote now
