XLR3F011B 3-pin female XLR Cable Connector – Black
Application / Description
This is a single shark shape female XLR cable connector used to transfer a balanced audio signal via 3 pins through an audio cable. Often used to terminate mic cables.
Features
- Shark series 3 pole female XLR cable connector
- Female connector with improved solid metal latch which is larger and easier to handle
- Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster
- Boot with Polyvinyl chloride gland gives high protection to cable bending stresses
- Rugged zinc diecast shell, long life and dependable
- Internal thread on shell is well protected against any damage
- Black housing
- Nickel plated
Specifications
| Model | XLR3F011B | XLR3M011B | XLR3F011 | XLR3M011 |
| type | 3 pole female XLR | 3 pole male XLR | 3 pole female XLR | 3 pole male XLR |
| Shell | die casted zinc alloy | die casted zinc alloy | die casted zinc alloy | die casted zinc alloy |
| Shell plating | Black housing | Black housing | nickel housing | nickel housing |
| Contact coating | nickel plated | nickel plated | nickel plated | nickel plated |
| Pole number | 3 | 3 | 3 | 3 |
| Type of contact | Soldering | Soldering | Soldering | Soldering |
| Cable O.D | Ø4-Ø7.5mm | Ø4-Ø67.5 mm | Ø4-Ø7.5 mm | Ø4-Ø7.5 mm |
| Packaging | Plastic bag | Plastic bag | Plastic bag | Plastic bag |
| Carton | 390*220*240 (500 pcs) | 390*220*240 (500 pcs) | 390*220*240 (500 pcs) | 390*220*240 (500 pcs) |
Packaging
- Plastic bag, paper box and blister packing are available;
- Special packaging on request.
