SMC20 Balanced Signal Microphone Cable

SMC20 Professional Low Noise Twin Conductor Microphone Cable – Spiral Shielding

Description

The SMC20 seires are a high-quality microphone cable with an ultra flexible outer jacket. A tight spiral shield for optimum noise rejection, thick conductors built using OFC (oxygen free copper). This twin conductor cable can be used to transfer either balanced or stereo audio signals.

Suited for use professional stage & studio applications. such as Microphones \ Portable Applications \ Audio Patch Cable \ PA Systems.

Features

2 x 0.22 mm² (24 AWG)
Stranded Oxygen-free copper
Ultra-high density spiral shielding
available in seven different colours
Ultra flexible PVC outer jacket
4.0 \ 5.0 \ 6.0 mm (Ø) outer diameter are available

Cross Section

Specifications

Cable model	SMC20	SMC21	SMC22H
Type of cable	Microphone cable	Microphone cable	Microphone cable
Conductor material	Bare stranded copper	Bare stranded copper	Bare stranded copper
Structure of conductor	7 x 0.15mm	20 x 0.12mm	20 x 0.12mm
Conductor section	0.123 mm²	0.23 mm²	0.23 mm²
American wire gauge	26 AWG	24 AWG	24 AWG
Insulation material	PE	PE	PE
Number of cores	2	2	2
Insulation colors	Red / Blue	Red / Blue	Red / Blue
Conductor twisting	Yes	Yes	Yes
Shielding	32 x 0.12mm BC – Spiral	64 x 0.12mm BC – Spiral	64x 0.12mm BC – Spiral
Filling	Cotton yarn	Cotton yarn	Cotton yarn
Separator	None	None	None
Outer jacket	Flexible PVC	Flexible PVC	Flexible PVC
Outer jacket color	Black matt	Black matt	Black matt
Outer jacket dimension	Ø4.0 mm	Ø5.0 mm	Ø6.0 mm
Electrical characteristics
Conductor resistance-100M	≤ 14.2 ohm	≤ 7.9 ohm	≤ 7.9 ohm
Capacity (C/C) ＠ 1kHz	55 pF/m	63 pF/m	63 pF/m
Mechanical characteristics
Temperature range	fixed installation		-20 °C to +70 °C
Temperature range	flexible installation		-15 °C to +60 °C
Bending radius	fixed installation		8 x outer diameter
Bending radius	flexible installation		10 x outer diameter
