AXLR3M01B  Low profile Rotatable 3 pole male XLR connector

Application / Description

This is shark shape low profile 320° rotatable angle male 3-pin XLR cable connector with Black housing used to transfer a balanced audio signal via 3 pins through an audio cable. Often used to terminate mic cables, Low profile and neat design, space saving.

Features

  • 3 pole female XLR cable connector
  • Low profile and neat design, space saving
  • Female connector with improved solid metal latch which is larger and easier to handle
  • Rugged zinc diecast shell, long life and dependable
  • Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster
  • High damping 160° up or 160° down rotatable bushing design, ensure clean and tidy wiring
  • Total 320° rotatable angle
  • Black housing
  • Color cover for idention

Specifications

Model AXLR3F01B  AXLR3M01B AXLR3F01 AXLR3M01
type 3 pole female XLR 3 pole male XLR 3 pole female XLR 3 pole male XLR
Shell die casted zinc alloy die casted zinc alloy die casted zinc alloy die casted zinc alloy
Shell plating Black housing Black housing  Nickel housing Nickel housing
Contact coating nickel plated silver plated nickel plated silver plated
Pole number 3 3 3 3
Type of contact Soldering Soldering Soldering Soldering
Cable O.D Ø3-Ø6mm Ø3-Ø6mm ØØ3-Ø6mm Ø3-Ø6mm
Packaging Plastic bag Plastic bag Plastic bag Plastic bag
Carton 390*220*240 (500 pcs) 390*220*240 (500 pcs) 390*220*240 (500 pcs) 390*220*240 (500 pcs)

Packaging

  • Plastic bag, paper box and blister packing are available;
  • Special packaging on request.
