Project Description

  • 6.3 mm mono JACK with black housing and gold plated JACK2M01B
  • 6.3 mm phone plug with gold plated amphenol type JACK2M01B
  • 6.3 mm TS JACK with gold plated amphenol JACK2M01B
  • amphenol shape Mono 6.3 mm plug with gold plated JACK2M01B
  • Mono 6.3 mm phone plug with black housing JACK2M01B

JACK2M01B  1/4″ (6.35 mm) Mono Jack Plug Soldering Audio Cable Connector -Black

Application / Description

This is a single male 6.35mm (1/4″) TS mono connector with black housing gold plated used to transfer a mono (unbalanced) signal through an audio cable.

Features

  • 1/4″ (6.35 mm) mono jack male plug
  • Metal strain relief provides higher pull-out force and makes assembly easier and faster
  • With PVC boot protection gives high protection to cable bending stresses
  • Rugged zinc diecast shell, long life and dependable
  • Black housing and Gold plated
  • RoHS Compliant

Specifications

Model  JACK2M01 JACK3M01  JACK2M01B JACK3M01B
type 1/4″ Jack Mono  Male Plug 1/4″ Jack Stereo Male Plug 1/4″ Jack Mono Male Plug 1/4″ Jack Stereo Male Plug
Shell Die casted zinc alloy Die casted zinc alloy Die casted zinc alloy Die casted zinc alloy
Shell plating nickel plated nickel plated Black plated Black plated
Contact coating nickel plated nickel plated Gold  plated Gold  plated
Pole number 2 3 2 3
Type of contact Soldering Soldering Soldering Soldering
Cable O.D Ø4-Ø7 mm Ø4-Ø7 mm Ø4-Ø7 mm Ø4-Ø7 mm
Packaging Plastic bag Plastic bag Plastic bag Plastic bag
Carton Packaging
Dimension (mm)
390*220*240 (500 pcs) 390*220*240 (500 pcs) 390*220*240 (500 pcs) 390*220*240 (500 pcs)

Packaging

  • Plastic bag, paper box and blister packing are available;
  • Special packaging on request.
